LUGONG
Model NO. | STS5K | STS10K | STS20K | STS30K | STS100K | STS200K | STS300K |
Maximum test force | 5000N | 10KN | 20KN | 30KN | 100KN | 200KN | 300KN |
Accuracy rating | 0.5 level | ||||||
Force measurement range | 1%~100%FS (full scale) | ||||||
Error of test force indication | Within 0.5% of the indicated value | ||||||
Force resolution | The maximum test force of ±1/300000 is not divided into bins throughout the whole process, and the resolution of the whole process remains unchanged | ||||||
Deformation measurement range | 0.2%~100%FS | ||||||
Deformation indication error | The ± of the indicated value is within 0.5%. | ||||||
Displacement resolution | 0.01mm | ||||||
| Displacement rate adjustment range | 0.01~500mm/min | ||||||
| Effective stretching stroke | 680mm (can be customized according to user needs). | ||||||
| Effectively compress the stroke | 1100mm (can be customized according to user needs). | ||||||
| Effective test wide size | 400mm(can be customized according to user needs). | ||||||
| Host dimensions | 700x550x2000mm (customizable size). | ||||||
| Host dimensions | 700x550x2400mm (plus working cabinet). | ||||||
| power supply | 220±10%VAC,50Hz,1.5kW | ||||||
Model NO. | STS5K | STS10K | STS20K | STS30K | STS100K | STS200K | STS300K |
Maximum test force | 5000N | 10KN | 20KN | 30KN | 100KN | 200KN | 300KN |
Accuracy rating | 0.5 level | ||||||
Force measurement range | 1%~100%FS (full scale) | ||||||
Error of test force indication | Within 0.5% of the indicated value | ||||||
Force resolution | The maximum test force of ±1/300000 is not divided into bins throughout the whole process, and the resolution of the whole process remains unchanged | ||||||
Deformation measurement range | 0.2%~100%FS | ||||||
Deformation indication error | The ± of the indicated value is within 0.5%. | ||||||
Displacement resolution | 0.01mm | ||||||
| Displacement rate adjustment range | 0.01~500mm/min | ||||||
| Effective stretching stroke | 680mm (can be customized according to user needs). | ||||||
| Effectively compress the stroke | 1100mm (can be customized according to user needs). | ||||||
| Effective test wide size | 400mm(can be customized according to user needs). | ||||||
| Host dimensions | 700x550x2000mm (customizable size). | ||||||
| Host dimensions | 700x550x2400mm (plus working cabinet). | ||||||
| power supply | 220±10%VAC,50Hz,1.5kW | ||||||
